QM series of horizontal ball mill, including liquid ball mill and dry powder ball mill. The series of ball mill performance and stability, can be widely used in paints, pharmaceuticals, building materials, chemical and other liquid or powder material dispersion grinding.
The main technical parameters:
specification | 50L | 100L | 200L | 300L | 500L | 1000L | 1500L | 2000L |
Grinding speed (r/min) | 55 | 50 | 50 | 50 | 45 | 40 | 35 | 35 |
Motor power (KW) | 2.2 | 3 | 4 | 4 | 5.5 | 11 | 15 | 18.5 |
Grinding volume (L) | 50 | 100 | 200 | 300 | 500 | 1000 | 1500 | 2000 |
Charge volume (L) | 20 | 40 | 90 | 130 | 200 | 450 | 700 | 900 |
Ball volume (L) | 25 | 50 | 100 | 150 | 225 | 500 | 750 | 1000 |
Weight (kg) | 100 | 220 | 360 | 510 | 780 | 1060 | 1600 | 2200 |
